Description
BioBlue Microscope BB.4200
The BioBlue microscope BB.4200 has a monocular head with Siedetopf 45° inclined tube 360° rotatable, DIN WF 10x/18mm eyepiece with pointer and semi plan achromatic objectives, 4x, 10x, S40x. The super sharp high resolution images of 40x, 100x, 400x magnification will remain perfectly in focus when changing magnification. All optics are anti-fungus treated and anti-reflection coated for maximum light throughput.
Condenser & Illumination
Height adjustable Abbe condenser N.A. 1.25 with iris diaphragm and filter holder. 1 W LED cordless illumination.
Supplied with an external 100-240 V mains adapter/charger and 3 rechargeable batteries for corded or cordless use. Easy transportation with ergonomic carrying handle.
Head
Monocular models with 45° inclined tubes, head is 360° rotatable.
Eyepiece(s)
Wide field WF 10x/18 mm eyepiece with pointer.
Nosepiece
Reversed nosepiece for four semi plan objectives.
Objectives
Semi plan Achromatic objectives 4x, 10x, S40x. All optics are anti-fungus treated and anti-reflection coated for maximum light throughput.
Focusing
Coaxial coarse and fine adjustments with 200 graduations. Precision 2 μm per graduation, 0.4 mm per rotation. Total travel approximately 23 mm. Supplied with an adjustable rack stop to prevent damage to sample and objectives. The coarse adjustment is equipped with friction control.
Stage
120 x 120 mm plain stage supplied with two non-removable object clamps.
Warranty: 5 years
Dimensions (mm): 320 (h) x 176 (w) x 227 mm (d). Weight 3.0 kg
Package Contents
Supplied with external 100-240 V mains adapter/charger and 3 rechargeable batteries for corded or cordless use, dust cover, spare fuse and user manual.
Accessories
Euromex offer a wide range of accessories which include a variety of digital cameras, eyepieces, objectives and lighting. Please refer to the relevant “ACCESSORIES” page.
